Description
Plastic housing & PS diffuser
IP20 or IP54 optional
3xCCT by DIP switch model available
Sidelit
Frame for surface mount available
P4
Plastic housing & PS diffuser
IP20 or IP54 optional
3xCCT by DIP switch model available
Sidelit
Frame for surface mount available
| Item | Wattage | Lumen | Voltage | Hole Size | Beam Angle | Dimension |
| P4-RR-3'-6 | 6W | 600lm | AC220-240V | 105-115mm | 110° | φ128×14.8mm |
| P4-RR-4'-9 | 9W | 900lm | AC220-240V | 130-135mm | 110° | φ145×15.8mm |
| P4-RR-6'-12 | 12W | 1200lm | AC220-240V | 150-160mm | 110° | φ170×15.8mm |
| P4-RR-8'-18 | 18W | 1800lm | AC220-240V | 205-210mm | 110° | φ225×16mm |
| P4-RR-12'-24 | 24W | 2400lm | AC220-240V | 280-290mm | 110° | φ300×16.3mm |
| P4-RR-12'-30 | 30W | 3000lm | AC220-240V | 280-290mm | 110° | φ300×16.3mm |
| P4-RS-3'-6 | 6W | 600lm | AC220-240V | 105-110mm | 110° | 120×120×14.8mm |
| P4-RS-4'-9 | 9W | 900lm | AC220-240V | 130-135mm | 110° | 145×145×15.8mm |
| P4-RS-6'-12 | 12W | 1200lm | AC220-240V | 150-160mm | 110° | 170×170×15.8mm |
| P4-RS-8'-18 | 18W | 1800lm | AC220-240V | 205-210mm | 110° | 225×225×16mm |
|
P4-RS-12'-24 |
24W | 2400lm |
AC220-240V |
280-290mm |
110° |
300×300×16.3mm |
|
P4-RS-12'-30 |
30W | 3000lm |
AC220-240V |
280-290mm |
110° |
300×300×16.3mm |
