Description
Die-cast aluminum housing+Frosted PC diffuser+PC frame
Cranked bracket or 3D bracket optional
15cm H05RN-F 3G 1.00mm2 rubber cable or quick connector optional
PIR sensor version available
TWA
Die-cast aluminum housing+Frosted PC diffuser+PC frame
Cranked bracket or 3D bracket optional
15cm H05RN-F 3G 1.00mm2 rubber cable or quick connector optional
PIR sensor version available
| Item | Wattage | Lumen | Voltage | IP | Beam Angle | Dimension |
| TWA10SX | 10W | 900lm | AC220-240V | IP65 | 110° | 117x34x107mm |
| TWA20SX | 20W | 1800lm | AC220-240V | IP65 | 110° | 127x34x108mm |
| TWA30SX | 30W | 2700lm | AC220-240V | IP65 | 110° | 142x37x121mm |
| TWA50SX | 50W | 4500lm | AC220-240V | IP65 | 110° | 181x37x156mm |
| TWA100SX | 100W | 9000lm | AC220-240V | IP65 | 110° | 240x37x222mm |
| TWA200SX | 200W | 18000lm | AC220-240V | IP65 | 110° | 336x43x291mm |
